CARBON · T300 · T700 · T800 · T1000 · M40J · M55J

Carbon Fiber

Carbon fiber sits at the top of the performance pyramid — specific strength and modulus far surpass glass fiber. T300 → T1000 covers everything from consumer (wind / automotive lightweighting / sports) to aerospace primary structure. Zhongfu Shenying / Guangwei / Hengshen have reached T800 aerospace-grade domestic production; Toray remains the high-end benchmark.

133

Matched materials

532

Typical property ranges

Density

1.76 – 1.95 g/cm³

Tensile strength

3.4 – 6.7 GPa

Young's modulus

220 – 570 GPa

Elongation at break

1.2 – 2.1%

Max service temp.

500 °C 以下（基体决定）

Cost position

¥¥¥ 高 · 结构级

BRANDS

Major brands

中复神鹰 Zhongfu Shenying

T300 / T700 / T800

威海光威 Guangwei

GW-T300-3K / 预浸料

江苏恒神 Hengshen

千吨级 T800 航空级

吉林化纤 Jilin Chemfiber

大丝束 48K 风电专用

INTL

日本东丽 Toray

T300 / T700S / T800H / T1000G / M40J / M55J

INTL

三菱化学 Mitsubishi / 东邦 Teijin

Pyrofil / Tenax

MATRIX · RESINS

Compatible resin systems

Click any resin to open the fiber × resin combination detail page — every matched material, formula, paper and patent in our DB.

EPEpoxy→BMIBismaleimide→CECyanate Ester→PEEKPEEK→PPSPPS→PAPolyamide→PFPhenolic→

PROCESSES

Compatible forming processes

These are industrially mainstream pairings for this fiber system; process parameters live under /tech and the formula library.

PULTRUSIONWINDINGRTMHP-RTMVARTMAFP

APPLICATIONS

Typical applications

WHERE

Main applications

Aerospace primary structure (wing / fuselage / doors) · Pultruded rods for wind blade spar caps · Automotive CFRP (B-pillar / battery shell / roof — HP-RTM) · High-pressure hydrogen tanks · Sports equipment · Satellite structure.

WHY

Why carbon fiber

5–10× specific strength of steel · High specific modulus · Fatigue-tolerant · Corrosion-resistant. Downsides: expensive (¥ 120-500 /kg) · Complex processes (autoclave / HP-RTM / AFP) · Strict resin requirements (epoxy / BMI / PEEK). Best when performance-to-weight is the deciding factor.
